| Names of values |
Ìårcury |
|
202.1 |
|
| Accuracy class |
2.0 (1.0) |
| Nominal voltage, V |
220 |
| Nominal \ max current, A |
|
5(50) |
|
| Network frequency, Hz |
50 |
| Sensitivity, VÀ |
5,5 (2,75)
|
| Power consumption, no more than, VÀ |
|
0,5 |
|
| Displaying device |
|
SM |
|
| Transmission ratio, imp/kWh |
|
6400 |
|
| Power line interface |
|
no |
|
| Working temperatures range, °Ñ |
|
-40…
+55 |
|
| Dimensions, mm |
204õ119õ56 |
| Weight, no more than, kg |
0,6 |
| Calibration period, years |
16 |
| Manufacturer’s warranty, years |
5 |
| Lifetime, years |
30 |
|
|
